26791 90° JIC Female 74° Cone Seat (SAE J514)
Part No.: 26791
JIC Female Swivel, Elbow 90
Material: Carbon Steel
Surface Treatment: Zinc Plated
Salt Spray Test: 96h
Sundon Machinery is a professional manufacturer since 2014, focus on hydraulic system components, including cutting ring fittings, transition fittings, and related products. Our products already be exported to Europe, the Middle East, South America, and other regions worldwide.
Share:
| Part No. | Thread E | HOSE BORE | DIMENSIONS | ||||
|---|---|---|---|---|---|---|---|
| DN | DASH | A | C | H | S2 | ||
| 26791-04-03 | 7/16"X20 | 5 | 03 | 26.5 | 9 | 30.5 | 15 |
| 26791-04-04 | 7/16"X20 | 6 | 04 | 30 | 9 | 33.5 | 15 |
| 26791-05-04 | 1/2"X20 | 6 | 04 | 30 | 9.5 | 34 | 17 |
| 26791-05-05 | 1/2"X20 | 8 | 05 | 33 | 9.5 | 37 | 17 |
| 26791-05-06 | 1/2"X20 | 10 | 06 | 35.3 | 9.5 | 39.3 | 17 |
| 26791-06-04 | 9/16"X18 | 6 | 04 | 30 | 10.5 | 34 | 19 |
| 26791-06-05 | 9/16"X18 | 8 | 05 | 33 | 10.5 | 37 | 19 |
| 26791-06-06 | 9/16"X18 | 10 | 06 | 35.3 | 10.5 | 39.3 | 19 |
| 26791-06-08 | 9/16"X18 | 12 | 08 | 35.8 | 10.5 | 39.8 | 19 |
